hobby metal working mill drill machine with auto feed table

Specifications

model ZAY7032A/1 ZAY7040A/1 ZAY7045A/1

drilling capacity 32mm 40mm 45mm

boring diameter 50mm 60mm 70mm

end milling capacity 20mm 32mm 32mm

face milling capacity 63mm 80mm 80mm

headstock travel(Z) 130mm 130mm 130mm

cross axis(Y) 165mm 165mm 165mm

longitudinal axis(X) 450mm 450mm 450mm

optional 650mm

table size 800X240mm (optional 1000*240mm)

motor power 750W 1100W 1500W

spindle speed 80-1250rpm 80-1250rpm 80-1250rpm

packing size 770*880*1160mm 770*880*1160mm 770*880*1160mm

weight 365kg 370kg 372kg

Located in Shanghai , we have been in this field for over 10 years . Now we mainly supply lathes , mills , drills , cncs for the hobby and industrial market with over 100 models for your choices.

So far ,we have enjoyed considerable good reputation from our customers all over the world because of the high quality and first-class after sale service.We are always trying to supply you better products and service . please contact us directly via shenlong@sumore.com .

Hope to cooperate with you!
